| Main function ： | ||
| 4G LTE data transfer | Frequency can be customized | Industrial design more stable |
| 2,4GWIFI | adapt to harsh environment | adapt to wide voltage |
| 4 pcs high gain antenna | 2LAN port | serial port |
| DTU | Montior device running status | watch dog design |
| Automatic repair, remote wakeup | Upgrade remotely | web management |
| Mian feature ： | ||
| 4G frequency can be customized | adapt to harsh environment | adapt to wide voltage |
| stable | Automatic repair, remote wakeup | Support online audit |
| Access technology | TD-LTE/FDD/WCDMA/TD-SCDMA/GGE(GSM/GPRS/EGPRS) |
|---|---|
| Frequency | GSM : 850/900/1800/1900 |
| TD-SCDMA：Band 34/39 | |
| WCDMA : Band 1/2/5/8 | |
| TD-LTE | Band 40/38/ 39/41 |
| FDD | Band 1/3/5/8 |
| speed rate | CAT4 DL:150Mbps / UL:50Mbps |
| indicators | power indicators , signal indicators ,LAN indicators |
| software | web management |
| power | DC 2.0(12V,1A) |
| reset button | 2个 LAN/RESET |
| antenna ability | for external antenna |
| SIM / USIM | Support SIM/USIM |
| configuraton upgrade | Unified network management, support local, platform firmware upgrade, configuration upgrade |
| software upgrade | Support local patch upgrade |
| working temperature | -20～50℃ |
| storage temperature | -40～85℃ |
| humidity | ≤95％ |
| SIZE | 108mm*100.5mm*24mm |
| weight | about 337.5g |
| Security | Support port filtering, IP filtering, MAC filtering, URL filtering, MAC address binding |
| speed control | Support uplink and downlink speed limit, port speed limit |
| WIFI speed | 2.4GHz,802.11b/g/n， |
| WIFI users | 32 |
