| Main functions | ||
| 2.4G wifi coverage | DC power supply | Home smart gateway；Control smart home terminals |
| Reduce Co-Channel Interference | RF optimization | Smart Broadcast Optimization |
| Support multiple SSID | 4LAN ports | Indoor placed |
| Support PPPOE dial-up Internet | Support 20 concurrent users | RF protection module |
| Support High gain antenna | Custom SSID&Encryption | Support indoor scene |
| The main selling point | ||
| Home core gateway ; Control smart home terminals | Suitable for multiple indoor scene hotspot | 4 external high gain antenna |
| APP control，manager the users | Support big data analysis, remote maintenance | Support Portal push，multiple SSIDmanagement |
| Chipset | MT7628NN |
|---|---|
| Frequency | 2.4G |
| Users | ≥20 |
| Speed | 300Mbps |
| Wifi Protocal | IEEE802.11n/802.11g/802.11b/802.3/802.3u |
| ROM /RAM | 64M/8M |
| Software | Remote cloud platform management |
| Power | DC9V 0.6A |
| Ports | 4* LAN,1 *WAN |
| LED | power/WLAN/WAN/LAN1/LNA2/LNA3/LNA4 |
| Antenna | 4 *Omnidirectional high frequency antennas |
| Config upgrade | Support local, platform firmware upgrade, configuration upgrade |
| Software upgrade | Support local patch upgrade |
